Greece: Range of circumstances and region analysis
Introduction
The majority of the countries of the Mediterranean region are characterized by a strong seasonal distribution of precipitation, which may be one of the main reasons for the water scarcity problems that they are facing.
Map 1.
Although
The permanent population of
Map 2. Surface waters in Greece
Table 1. Summary of
Background |
Description |
Climate |
The annual precipitation varies
from 200 mm in the plains and insular regions, to 2150 mm in the mountainous
regions. |
Geomorphology |
In |
Geology |
Formations are mainly comprised of
limestone (with many karstic horizons) and sedimentary rocks (flysch,
schistones, etc). There are also metamorphic, igneous and volcanic rocks, as
well as tertiary and quaternary deposits. |
Ground
Water |
Many aquifers have been formed primarily
in the sedimentary materials and the estimated amount of stored ground water
is 10,300 hm3/year. |
Surface
Water |
There are 765 recorded streams, 45
of which are perennial. Four rivers flow from the northern
countries into |
Water storage features |
Dams of differing capacities have
been constructed for domestic supply and irrigation purposes and the production of
hydroelectric power. There are also several small
water reservoirs that are used mainly for irrigation. |
Map3. Precipitation in
Almost 100% of the Greek population is
connected to water supply and power utilities, while 76% of the population is
connected to sewerage and wastewater treatment networks. Generally, water
demand in
There is a lot of data regarding the
natural environment for the majority of
· Regarding domestic and industrial water use, there are data on urban areas and the biggest settlements, which may be made available by the water companies and utilities. In smaller communities, the data are scarce and non-dependable. Overall, data are mostly available where organized water utilities operate.
· Regarding agricultural water use, the volumes are usually estimated on the basis of the area of irrigated land (according to the Greek statistical services) multiplied by an index of irrigation requirement according to cultivation type. Since a large part of the water used for irrigation is obtained through private drills, often without a license, there are no exact measurements of the full volume of water used for irrigation, but only of the volumes provided by the local public irrigation networks.
Table 2. Annual water balance
|
Flows (hm3/y) |
Precipitation |
113,402 |
Surface water evapotranspiration losses
(assumed as 50% of precipitation) |
-56,701 |
Surface water flows |
58,700 |
Groundwater flow |
10,300 |
Net potential surface and groundwater
available |
69,000 |
Net exploitable surface and groundwater |
5,480 – 7,940 |
In some parts of the country, in addition
to the limited water resources, water pressure may also be attributed to the large
influx of visitors from other parts of the country or from abroad. Figures for
tourist arrivals vary from year to year and between measurements. The
About 14 km3/y of water
entering
Map 4. Potential Evapotranspiration in Greek hydrological basins
Given the water scarcity observed in parts of the country, conflicts are unavoidable:
· In urban centers, where the main area
for conflict is the transfer of water from other, richer in water resources regions,
or the exploitation of water resources that would be used for irrigation. Cases
of water deficient urban centers are the Metropolitan Athens area and
· In agricultural areas, where conflict arises due to the excessive
usage for irrigation purposes of water that could
be used for domestic supply, tourist activities, and
for maintaining the ecological characteristics of the surface and ground water
of the area. The agricultural activities and practices in
· In areas dependent on tourism, and particularly in the Aegean islands, conflicts are very intense. During the summer months, water demand reaches its peak both for irrigation and domestic supply; in some islands the summer peak can reach up to thirty times the domestic needs of the permanent population. As the domestic supply takes priority over the use for irrigation, conflicts invariably arise between the municipal water suppliers and the local farmers. Water resources in the Greek islands are very limited, and with few exceptions consist of groundwater contained in the local aquifers. The amount of water that can be abstracted is limited, as overabstraction of those aquifers leads to salinization of the water rendering it mostly unusable. The soils in the islands are extremely vulnerable to erosion, with resulting problems in the water resources (reservoir sedimentation, stream bed stability etc.). In this regard, the future of the islands may be threatened by increasing stress in the coastal areas, expanding differences between tourist areas and the rural hinterlands, serious water resources interdependencies, high susceptibility to pollution, and the sensitivity between the water and soil equilibrium.
Table 3. Available water resources in the 14 Water regions1
Water
Availability (hm3) |
ÊEPÅ
(1972) |
AGELAKIS
(1989) |
MINISTRY OF DEVELOPMENT (1996) |
||||||
Estimated
Surface Water |
Exploitable
Groundwater |
Total |
Surface
Water |
Ground
Water |
Total |
Surface
Water |
Ground
Water |
Total |
|
01 |
2720 |
150 |
2870 |
3050 |
700 |
3750 |
3534 (runoff) |
423 (potential) |
4400 (potential) |
02 |
3200 |
100 |
3300 |
2650 |
900 |
3550 |
2280 (runoff)5 |
400 (exploitable) |
3940
(potential) |
03 |
1243 |
108 |
1351 |
1000 |
950 |
1950 |
- |
- |
- |
04 |
11649 |
100 |
11749 |
9750 |
850 |
10600 |
5296 (potential) |
3384 (potential) |
8680 |
05 |
8591 |
56 |
8647 |
8500 |
250 |
8750 |
5938 (runoff) |
4412 (potential) |
10350
(potential) |
06 |
219 |
20 |
239 |
200 |
200 |
400 |
259(potential) |
190 (potential) |
449 (potential) |
07 |
1815 |
280 |
2095 |
1900 |
750 |
2950 |
2874 (potential) |
1673 (potential) |
|
08 |
3424 |
655 |
4079 |
3250 |
1350 |
4600 |
2558 (potential) |
506 |
3064 |
09 |
4388 |
300 |
4688 |
4100 |
850 |
4950 |
- |
- |
- |
10 |
6299 |
256 |
6555 |
69008 |
624 (344)4 |
77444 |
- |
- |
- |
11 |
46009 |
200 |
4800 |
420010 |
550 |
50693,4 |
- |
- |
- |
12 |
1099111 |
180 |
11171 |
1090012 |
400 |
11300 |
1027713 |
485 |
10762 |
13 |
1564 |
105 |
1669 |
1300 |
1300 |
2600 |
1558 |
130014 |
2858 |
14 |
856 |
49 |
905 |
1000 |
250 |
1250 |
1561 (potential) |
527 (potential) |
2088 |
Table 4. Water consumption in the 14 Water regions
Water
Consumption (hm3) |
ÊEPÅ
(1972) |
AGELAKIS
(1989) |
MINISTRY OF DEVELOPMENT (1996)15 |
||||||||||||
Domestic
Use |
Irrigation |
Industry |
Total |
Domestic
Use |
Irrigation |
Industry
– Energy |
Total |
Domestic
Use |
Irrigation–
Animal Husbandry |
Industry
– Energy |
Total |
||||
Surface Water |
Ground Water |
Surface
Water |
Ground
Water |
Surface
Water |
Ground
Water |
||||||||||
01 |
5 |
3.2 |
72 |
18 |
1 |
0.8 |
107 |
22 |
200 |
12 |
234 |
23 |
206 |
23 |
252 |
02 |
9 |
7 |
118 |
32 |
3 |
3 |
174 |
37 |
400 |
3 |
440 |
41.7 |
408.1 |
3 |
452.8 |
03 |
7 |
3 |
70 |
75 |
1 |
2 |
158 |
17 |
200 |
3.5 |
220.5 |
- |
- |
- |
- |
04 |
5.9 |
1.8 |
174 |
20 |
0.1 |
0.2 |
202 |
15 |
260 |
0.5 |
275.5 |
22.4 |
376.9 |
|
398.3 |
05 |
8.2 |
2 |
120 |
18 |
0.8 |
1 |
150 |
28 |
230 |
4 |
262 |
42.64 |
385.4 |
1 |
429.05 |
06 |
124.418 |
11.719 |
3 |
10 |
7.6 |
1.3 |
158 |
255 |
70 |
17 |
342 |
289 |
101.5 |
17.5 |
408 |
07 |
9 |
5 |
99 |
26 |
3 |
2 |
144 |
36 |
380 |
5.5 |
421.5 |
165.916 |
783.6 |
12.6 |
962.1 |
08 |
12 |
13.1 |
127.5 |
297.5 |
2.5 |
5.4 |
458 |
58 |
720 |
7 |
785 |
53.7 |
1580.5 (1297.2) |
|
1634.2 (1350.9) |
09 |
14 |
4 |
285 |
24 |
- |
- |
338 |
40 |
370 |
30 |
440 |
- |
- |
- |
- |
10 |
1.7 |
27.6 |
229 |
81 |
14.3 |
6.4 |
360 |
72 |
280 |
20 |
372 |
- |
- |
- |
- |
11 |
2 |
10 |
187 |
25 |
- |
7 |
231 |
23 |
390 |
9.5 |
422.5 |
- |
- |
- |
- |
12 |
2.9 |
6.9 |
125 |
25 |
0.1 |
0.1 |
160 |
27 |
420 |
6 |
453 |
248.121 |
2.57 |
2.57 |
253.17 |
13 |
9.8 |
3.0 |
67 |
45.7 |
0.2 |
0.3 |
126 |
33 |
220 |
2 |
255 |
42.33 |
330.2 |
|
372.53 |
14 |
8 |
4.0 |
21.9 |
27.6 |
0.1 |
0.4 |
62 |
33 |
80 |
1 |
114 |
37.19 |
87 |
|
124.19 |
Overall, the coastal waters of
Domestic effluents and agrochemicals are a major source of surface and groundwater pollution in many parts of the country. Despite the existing EU legislation for all communities with a population above 2000 inhabitants to be connected to wastewater treatment plants by the year 2000, such progress could not be documented. The quality of Greek river systems is also dependent on the time of the year. Water levels decrease significantly in the summer, thus allowing higher concentrations of pollutants. Furthermore, overabstraction and saline intrusion in the underground aquifers exacerbates the problem of groundwater deterioration and increases the water shortage problems.
Map 5. Quality and quantity problem areas
Another issue that should be mentioned
is the occurrence of periodic droughts and floods, occurring in increasing
frequency in the recent years. In the last decade, there were two serious
droughts that affected the country, and particularly the capital city which
depends on massive water transfers. The combination of prolonged drought periods with
intermittent floods after torrential rainfall also worsens the pollution
problems of urban and agricultural runoff, particularly in large urban centers
like
The administration and management of water is at the moment undergoing major changes due to the process of Greek legislation harmonization with respect to the European Water Framework Directive. At present, new legislation has been announced but not yet submitted for approval to the Parliament. Therefore the description of the institutional framework and management of water resources in the following paragraphs refers to the current situation and does not reflect the Water Framework Directive values and principles.
In the Greek legal system there is
a wide framework of laws and regulations for the allocation of water resources, the
management of water resources and services, and the quality and quantity
aspects of water regarding each use. According to Article 24 of the Greek
Constitution, the protection of the natural environment is not only a
responsibility of the state, but also of the citizens. The state is under
obligation to take preventive and corrective measures for the protection of the
natural environment in the framework of sustainability. These measures should
be taken both on the legislative and the administrative level.
The protection of water resources is also
regulated by a number of international agreements and legislation, such as the
Ramsar international agreement on the protection of internationally
important wetlands. Several EU directives on the protection of waters and
public health have been adapted by the Greek legislation (98/83/EC, 91/767/ EC,
87/217/ EC, 86/280/ EC, 84/491/ EC, 83/513/ EC, 82/176/ EC, 80/68/ EC).
Law 1650/1986 regulates the sampling and ascertaining the quality of water, depending on the type of the receiving waters that require protection and the sensitivity of the local ecosystems. It also proposes a group of measures and limits for the protection of waters from building projects and activities, effluent and usable water standards, sampling and measuring equipment etc (Article 10).
Map 6. Districts and Prefectures of
Of the Greek legislation, the most important ones regarding the administrative aspect of the resource are laws 1739/1987 and 1069/1980, which formulate the general framework of water management and the framework of municipal water supply respectively.
Law 1069/1980 regulates the foundation and operation of municipal water supply utilities. According to the law, any municipality with a population over 10,000 people can proceed to create a public water utility. The municipality’s responsibilities for water supply, sewerage services, and refuse collection are transferred to the utility, which also assumes the ownership of all networks and infrastructure related to those duties, as well as the responsibility for the provision, financing and monitoring the quality of services. It should be stressed that free flowing waters are characterized by the Article 967 of the Civil Law as communal resources that cannot be traded. Therefore, they are not part of the holdings of the municipal utilities or authorities, but rather resources that can be exploited for public, municipal or religious uses.
Law 1739/1987 regulates all procedures
and administrative instruments that will allow the management and protection of
water resources on the national and regional level. The law defines water
resources to include all surface and groundwaters, regardless of quality,
origin or potential use, the waters of natural springs, inland or marine, and
the waters of thermal and gaseous springs. This law functions as a framework
for the administration, rather than actual management, of water resources. It
defines the responsible authorities and instruments, and elaborates on the
responsibilities of existing structures (e.g. the ministries, the Power utility
etc). It also legislated the creation of new instruments for effective water
management in
The Department of Water and Natural Resources is based in the Ministry of Development, which supervises also the Interministerial Water Commission. The Interministerial Water Commission, created by law 1739, acts as a consulting body for the formulation of the national water policy. Concurrently, the country was divided into fourteen water regions, and Regional Water Commissions and Regional services of Water Resources Management were introduced as branches of the Ministry of Development.
So far, law 1739/1987 has yet to be fully implemented as most of these agencies are not fully functional. One of the major disadvantages of the current institutional framework for the management of water resources is the fragmentation and scattering of responsibility among different agencies, which leads to overlaps in responsibility and difficulty in coordinating the actions of the different authorities. Table 5 in the following section summarizes the authorities responsible for the different aspects of water management according to law 1739/1987.
Responsibility on water allocation and management is distributed in the national, regional and local levels of administration. The initial allocation of water is effected by the Ministry of Development, which is responsible for water allocation to individual uses, as well as for the management of water designated for industrial use. Once the initial allocation has been made, the water for each use falls under the responsibility of the respective ministry. Noteworthy are the Ministry of Agriculture, responsible for the use of water in irrigation, the Ministry of the Interior, responsible for the use of water for municipal water supply with the exception of the cities of Athens and Thessaloniki, and the Ministry of the Environment, Urban Planning and Public Works (MEUPPW), responsible for the use of water for the water supply of Athens and Thessaloniki and the conservation of the quality of the environment (See Figure 1).
The most pressing issue is that there are many government departments dealing with water problems, but their activities are compartmentalized and not well coordinated. Added to this is a water law system which is not responsive to modern issues of an industrial society and widely scattered, thus permitting overlapping functions, multiple advisory bodies and insufficiently decentralized management responsibilities through regional organizations. A Master Plan has yet to be formulated, along with the corresponding management principles for the 14 water regions. Legislation also tends to be deficient in the case of pollution issues, where quality standards for water bodies and/or effluent disposal have not been clearly established. Furthermore, the sporadic consideration of water quality issues in a coherent water policy and the absence of systematic, uniform and enforceable pollution charges have compounded problems and have handicapped water resources management efforts.
Figure 1. Water Governance in the National Level
On the regional level, the regional authorities are responsible for the approval of planning and financing for projects involving water supply and irrigation. Prefecture authorities are responsible for the issuing of permits for abstraction and for the allocation of water within each region/use. On the local/municipal level, the municipality is responsible for the supply water and services to the people, or, for the creation of public companies responsible for the provision of water and sanitary services, (see table 5).
Table 5. Responsible Authorities in the Water Sector
Agency/Authority |
Responsibilities |
Ministry
of Agriculture |
Use in
irrigation and animal husbandry |
Ministry
of the Interior |
Supervising
Municipal water supply, except for |
Ministry
of the Environment |
Protection
of water quality and quantity |
Ministry
of Development |
Responsibility for the allocation of water to use sectors |
Ministry
of Transportation |
Use of
water in transportation |
Ministry
of Culture |
Use of
water in sports |
Ministry
of Foreign Affairs |
International
water issues |
Ministry
of Health and Welfare |
Undertaking
and participation in water resources management research programmes |
Regional
Authorities |
Approval
of municipal decisions for the creation of Water Utilities, the extension of
the duties of Water Utilities, or the participation of other municipalities
in Water Utilities |
Prefecture
Authorities |
Issuing of
water use licenses |
Municipal
Authorities |
Provision
of water services |
National
Tourism Organization |
Use of
water in recreation and therapeutic spas |
Public Power
Corporation, |
Undertaking
and participation in water resources management research programmes |
Map 7. The 44 hydrological basins of Greece
Currently the
focus in
Table 6. The development priorities
Area
type |
Development
Priorities |
Urban |
Meeting the needs of maintaining infrastructure (transport,
water supply and sewerage, refuse disposal areas) |
Agricultural |
Promoting less intensive agriculture practices. Reuse and
conservation. |
Tourist destinations |
Improving the tourist quality
to higher income groups |
As the local authorities are responsible for water use, with the exception of protected water bodies and areas, the management of water resources is often found to be poor and disorganized. Maintenance of infrastructure in the more remote areas tends to be poor, while long term contingency planning is almost non-existent. Financial constraints are the main reason behind the poor management and lack of planning (see table 7). Responses to water shortages vary depending on the area and the conditions.
Overall they tend to be short-term responses, driven by crises that require the confrontation of the acute shortages. In cases of water shortage, supply augmentation management options are the most often used. Demand reduction management principles have been used in the past, particularly in the Athens Metropolitan Area in the early 1990’s, where increased water prices were successfully used to compensate for the prolonged drought that had led to severe water shortages. The limited demand reduction management responses applied are not widely used, as the price of water tends to play a pivotal role in political processes; the growth of the greater capital area has overall been supported by a series of reservoirs and abstractions from the western parts of the country.
Generally, the means used to confront
water shortages have depended mainly on the cost of the method. Hence, the
first response to water shortages invariably involves new drilling of the
aquifers. Groundwater is extensively used both for domestic and irrigation
water supply throughout the country, and particularly in the
In cases where the quality or quantity of groundwater does not meet the required standards, an alternative way of ensuring water supply is importing water from neighboring, richer in water resources areas (water hauling by ships, underwater pipes etc). For permanent water shortage other structural solutions are preferred. Dams and reservoirs are used where there are funds available, and locations suitable, for their construction; alternatively, desalination plants are also used in cases of more limited funds or lack of suitable locations.
Table 7. Constraints facing the water sector
Category |
Constraints |
Natural |
Uneven water resource distribution |
Human |
Uneven population distribution |
Technical |
Local authorities lack the technology, know how and specialised
personnel needed for long term management and for the construction and particularly
maintenance of water infrastructure |
Financial |
Deficient allocation of funds to the remote regions, exacerbated by
the multitude of responsible authorities |
Administrative
and institutional |
Lack of well defined, long-term water policy |
There is great need for new approaches to
water management that will serve to mitigate at least some of the above problem
issues and constraints, and promote sustainable use of the available resources
while aiding to achieve the aims of development policies. It may also be
pointed out that the traditional spatial environmental view has been exploded
and project boundaries - and their impacts and consequences - are becoming much
more diffuse. A strategic approach is needed that should include drastic
measures of ecological rehabilitation, innovative institutional mechanisms, and
a balance between autonomy and cooperation. Such integrated approaches should
incorporate environmental monitoring and information by expanding the factual
basis of holistic urban/industrial water management models. In addition, they
should also be accompanied by a framework for negotiations that stresses the
importance of comprehensive institutional formats and the clarity in local and
national decision making processes.
Table 8. Water Resources Planning Matrix
Activity |
Municipal Authority/ Water Utility |
Regional Authorities |
Prefecture Authorities |
Ministry of Development |
Ministry of Environment |
Ministry of Agriculture |
Ministry of Finance |
Surface water |
|
|
|
|
|
|
|
Use |
X |
|
|
X |
|
|
|
Storage |
X |
|
|
|
X |
X |
X |
Recharge |
|
|
|
|
X |
|
|
Diversion |
|
|
|
X |
X |
X |
|
Quality monitoring |
|
|
|
|
X |
|
|
Assessment |
|
|
|
|
X |
|
|
Ground water |
|
|
|
|
|
|
|
Use |
X |
|
|
X |
|
|
|
Storage |
X |
|
|
|
X |
X |
|
Recharge |
|
|
|
|
X |
|
|
Quality monitoring |
|
|
|
|
X |
|
|
Assessment |
|
|
|
|
X |
|
|
Well/drill permits |
|
|
X |
|
|
|
|
Irrigation network |
|
|
|
|
|
|
|
Rehabilitation |
X |
|
X |
|
|
X |
|
Modernization |
X |
|
X |
|
|
X |
|
Reuse |
|
|
|
|
|
|
|
Drainage water |
|
|
|
|
X |
X |
|
Wastewater |
|
|
|
|
X |
X |
|
Desalination |
X |
|
|
X |
X |
|
X |
Introduction of technology |
X |
|
|
X |
|
|
|
Efficient water utilization |
|
|
|
|
|
|
|
Domestic |
X |
|
|
|
|
|
|
Industrial |
|
|
|
X |
|
|
|
Irrigation |
|
|
|
|
|
X |
|
Legislation |
|
|
|
|
|
|
|
Regulation and codes |
|
|
|
X |
X |
X |
|
Standards |
|
|
|
|
X |
|
|
Policy setting |
|
|
|
X |
|
|
|
Water allocation |
|
|
|
X |
|
|
|
Project financing |
X |
X |
X |
|
|
|
X |
Project design |
X |
X |
X |
X |
|
|
|
Project Implementation |
X |
|
|
X |
|
|
|
Operation and maintenance |
X |
|
|
|
|
|
|
Pricing |
X |
|
|
|
|
|
|
Enforcement |
X |
|
|
|
|
|
|
Water
Data records |
|
|
|
X |
X |
X |
|
The main constraints and problem issues are the following:
v
Dependence
on transboundary waters flowing from non-EU regions. Waters flowing from non-EU
regions are very difficult to regulate, particularly in matters of quality; the
lack of infrastructure in the neighboring countries results in pollution
downstream into Greek waters.
v Strong
dependence on irrigation. Even with the best management techniques and
strategies, agriculture will remain the major user of water in the country, due
to the hot and dry climate.
v
Pronounced
seasonality of demand, which makes the provision of water services harder, as
it is not always possible to ensure adequate supply.
§
The
demand that is due to tourism peaks in the summer when a major influx of
tourists is observed.
§
The
demand for agriculture peaks in the dry hot season, the same time as the domestic
demand peaks due to tourism.
v
Uneven
distribution of resources. Both precipitation and surface water resources are
concentrated in the western and northern parts of the country which are self-sufficient,
while the eastern and southern parts of the country face water shortages.
v
Uneven
distribution of population. Overall, the population is concentrated in the eastern
coastal areas which tend to be under stress. Furthermore, the concentration of
almost half the Greek population in
v Overexploitation
and salinization of aquifers, a common problem in the areas dependent
on groundwater and particularly in coastal areas.
v Water
quality deterioration due to human activities.
v Focus
on short-term developmental policies rather on the actual water resource
management.
v
Lack
of inter-ministerial coordination and overlaps in areas of authority. Instead of
an organized, coordinated approach to water resources management, measures
taken are only partial and generally ineffective.
v Absence
of master plans or national guidelines for comprehensive planning and
management in the past, despite recent efforts for responding to that problem.
v Lack
of organized, collective efforts, which are required to respond to the
demanding provisions of the Water Framework Directive and other EU legislation
and operational guidelines.
Map
8 illustrates the aridity indices
in the different Hydrological basins in
v
v
v
The
Aegean islands and the southern part of
Map
8. Aridity Index in
Greek Hydrological basins
Map 9 shows the regions selected for further study. The selection of these regions was made based on the water deficiency and aridity of the area, as mentioned above, but also on its social and economic characteristics. Each one of these three regions suffers water deficits for a different reason, which makes them good candidates for study:
1.
2.
The
3.
The
Map 9. The Candidate Regions selected
These three regions will be analyzed in the following section as to their respective sets of circumstances, affecting water resources and management.
